Yamato BO-400 Compact Digital Oil Bath
Yamato BO-400 Compact Digital Oil Bath, 4L 100-120V 10.5-12.5A
Easy to use, digital setting, compact design oil bath
Features
- Digital temperature setting by ā²ā¼ keys
- Removable oil tank for convenient cleaning and changing of oil
- Heater situated outside the water tank
- Exclusive connection for bath operational setting function with RE601/801 rotary evaporator
Specifications
| Operating Temp. Range | Room temp. +10~180Ā°C |
| Temp. Control Accuracy | Ā±2Ā°C (at agitation) |
| Temp. Control System | PlD control by microprocessor |
| Temp. Setting / Display Method | Digital setting by ā²/ā¼ keys |
| Operation Function | Fixed temperature, quick auto-stop, auto stop, auto start |
| Additional Function | Keypad lock, RE signal transmission and reception, power failure recovery, calibration off-set |
| Heater | 1.44kW (120V) |
| Sensor | K thermocouple |
| Safety Device | Bath protection cover (ABS heat-resistant resin) Self-diagnostic function (automatic overheat prevention, temperature sensor error, triac short circuit, heater disconnection, main relay failure), circuit protector, thermal fuse, micro switch to detect heating without oil |
| Interlocking Control Function | RE601/801 signal transmission and reception (constant operation, heat retention operation, stop), Error report to RE601/801 |
| Water Tank | Capacity: ~4L Dimensions: Max. I.D.240 x bottom Dia165 x D122mm |
| External Dimensions | W340 x D349 x H231mm |
| Weight | ~5.5kg |
| Power Source (50/60 Hz) | AC100~120V 12.5~10.5A |
Ā
This product ships directly from Yamato, ensuring fast delivery, proper handling, and factory quality. When you purchase Yamato, youāre backed by a trusted name in laboratory equipmentāknown for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
