TrueChrome Metrics provides extremely powerful measurement functionalities including, freehand line, rectangle, polygon, circle, bicircle, angle, point-line distance and much more, realizing precise measurement of point and line distance, angle, length, circumference and area. Three different length units of millimeter, centimeter, and micrometer are provided to meet various measurement requirements indifferent application



Specifications

Sensor Model	SONY IMX307LQR-C
Sensor Type	CMOS
Sensor Size	1/2.8"
Color/Mono	Color
Preview Resolution	2MP (1920x1080)
Video Recording	30fps@SD 30fps@PC
Frame Rate	[email protected] 30fps@HDMI
Shutter Mode	Rolling
Exposure Mode	Auto/Manual
Picture Format	TIFF/JPG/PNG/DICOM
Operating System	Windows 7/8/10, Mac
PC Software	Mosaic V 2.1
SDK	C/C++, C#, Directshowt
Picture Format	JPG / PNG / TIFF
Data Interface	USB2.0,SD,HDMI
Optical Interface	Standard C Mount
Camera Size	90.7x78x70.8(mm)
Camera Weight	448g

Efficient image acquisition - editing - measurement - report output
From the user's point of view, redefining the image acquisition - editing - measurement - report output workflow process, taking into account the best operating procedures, greatly saves the operating time, effectively improving productivity.

Excellent imaging performance for brightfield, fluorescence and polarized imaging needs
The use of Tucsen's core ISP color-interpolation algorithm effectively corrects the color deviation of the sensor's spectral response, to simulate the human eye's sensitivity to color. The true color in the eyepiece, whether it is a biological bright field, stereo or fluorescence image.

Software

Tucsen Camera Quick Start Guide
