General Specifications:

Model	Capacity [ Cubic Feet ]	Capacity [ Liters ]	Temp. Range [ °C ]	Temperature Range [ °F ]	Exterior [ Inches ]	Interior [ Inches ]	Exterior [ Centimeters ]	Interior [ Centimeters ]
DHK4-10SD	10 Cu. Ft.	283 Liters	2°C to 8°C	36°F to 46°F	24" x 22" x 60"	19.5" x 17" x 50"	60 x 55 x 152	49 x 43 x 127
DHK4-10GD	11.12 Cu. Ft.	315 Liters			25.75" x 26.5" x 69.5"	22.75" x 21" x 44"	65 x 67 x 176	58 x 67 x 112
DHK4-14SD	14 Cu. Ft.	395 Liters			25.75" x 26.5" x 78.5"	23" x 21" x 53.25"	65 x 67 x 199	58 x 53 x 135
DHK4-23GD	23 Cu. Ft.	650 Liters			28.25" x 35" x 78.25"	23.75" x 28.5" x59.75"	72 x 89 x 199	61 x 73 x 152
DHK4-23GD-T	23 Cu. Ft.	650 Liters			28.25" x 35" x 78.25"	23.75" x 28.5" x59.75"	72 x 89 x 199	61 x 73 x 152
DHK4-49GD	46.62 Cu. Ft.	1320 Liters			57.25" x34.75"x78.75"	52.75" x 26.25" x59.5"	145 x 88 x 200	134 x 67 x 152
DHK4-49GD-T	46.62 Cu. Ft.	1320 Liters			57.25" x34.75"x78.75"	52.75" x 26.25" x59.5"	145 x 88 x 200	134 x 67 x 152



Product Specifications:

Model	Voltages Available	Amperage	NEMA Configuration	Certification(s)
DHK4-10SD	115 Volts 60 Hertz 1 Phase	15 Amp Dedicated Line 1.8 Running Amps	NEMA 5-15	UL Listed
DHK4-10GD		15 Amp Dedicated Line 1.35 Running Amps
DHK4-14SD		15 Amp Dedicated Line 3.77 Running Amps
DHK4-23GD		15 Amp Dedicated Line 4.92 Running Amps
DHK4-23GD-T		15 Amp Dedicated Line 4.92 Running Amps
DHK4-49GD		15 Amp Dedicated Line 10.06 Running Amps
DHK4-49GD-T		15 Amp Dedicated Line 10.06 Running Amps



Electrical Specifications:

Model	Temp. Control	Touch screen	Min / Max Temp.	Temp. Alarm	Alarm Types	Data Logging	Data Download	Backup Battery	Alarm Relay
DHK4-10SD	Digital Display	n/a	Display and Reset	Audible High / Low Alarm	Dry Contacts	n/a	n/a	n/a	n/a
DHK4-10GD		n/a			Door Ajar, Power Failure, Low Battery, Sensor Failure, USB Failure	Adjustable Intervals	Via USB. PDF Format	Only Powers Alarm	Dry Contacts
DHK4-14SD		n/a
DHK4-23GD		n/a
DHK4-23GD-T		Color Display
DHK4-49GD		n/a
DHK4-49GD-T		Color Display
