Scilogex Chest Style Freezers to -45°C | So-Low

Low temperature chest style freezers comes standard with microprocessor digital controller, audible and visual alarms, alarm battery back-up, and a 90 days labor 1 year parts warranty. MADE IN USA. NATIONWIDE SERVICE.

Product Specifications:

Model Capacity
[Cubic Feet]		 Capacity
[ Liters ]		 Temperature Range [ °C ] Temperature Range [ °F ]
 Dimensions Exterior
[ Inches ]		 Interior
[ Inches ]		 Exterior
w x d x h (cm)		 Interior
[ Centimeters ]
CH40-3 3.5 Cu. Ft. 99 Liters 0°C to -40°C 32°F to -40°F [ W x D x H ] 22" x 23.5" x 34" 15.75" x 17" x 25.87" 55.9 x 59.7 x 86.4 40 x 43.2 x 65.7
CH40-5 5 Cu. Ft. 142 Liters 29" x 24" x 33.63" 24" x 15.25" x 26" 73.7 x 61 x 85.4 60.1 x 38.7 x 66
CH45-3 3.5 Cu. Ft. 99 Liters 0°C to -45°C 32°F to -49°F 22" x 23.5" x 34" 15.75" x 17" x 25.87" 55.9 x 59.7 x 86.4 40 x 43.2 x 65.7
CH45-5 5 Cubic ft. 142 Liters 29" x 24" x 33.63" 24" x 15.25" x 26" 73.7 x 61 x 85.4 60.1 x 38.7 x 66
CH40-9 9 Cu. Ft. 255 Liters 0°C to -40°C 32°F to -40°F 39" x 23.5" x 33.5" 33.5" x 17.5" x 27.5" 99 x 59 x 85 85 x 44 x 69
CH40-15 15 Cu. Ft. 424 Liters 55.5" x 29.75" x 34.38" 9.25" x 21.63" x 25.75" 140.1 x 75.6 x 87.3 125.1 x 54.9 x 65.4
CH40-20 20 Cu. Ft. 566 Liters 74" x 30" x 34" 67" x 21.5" x 25" 188 x 76.2 x 86.4 170.1 x 54.6 x 63.5
CH40-25 25 Cu. Ft. 707 Liters 83.25" x 32" x 33.75" 76.75" x 23.5" x 24.88" 211.5 x 81.3 x 85.7 194.9 x 59.7 x 63.2



Electrical Specifications:

Model Voltages Available Amperage NEMA Configuration Certification(s)
CH40-3 115 Volts 60 Hertz 1 Phase 15 Amp Dedicated Line 2 Running Amps NEMA 5-15 ETL Listed
CH40-5
CH45-3
CH45-5
CH40-9
CH40-15 15 Amp Dedicated Line 3 Running Amps
CH40-20
CH40-25



Control Specifications:

  • Temperature Control             Digital Display

  • Min/Max Temperature          Yes, Display and Reset

  • Temperature Alarm               Audible High / Low Alarm

  • Alarm Types                           Power Failure, Low Battery

  • Backup Battery                      Yes, Only Powers Alarm

  • Alarm Relay                           Dry Contacts

General Specifications:

Model CH40-3 CH40-5 CH45-3 CH45-5 CH40-9 CH40-15 CH40-20 CH40-25
Defrost Manual
Air Circulation Gravity Flow
Compressor(s) Hermetic Compressors
Refrigeration R290 R404A
Insulation Polyurethane Foam
Opening Top Opening Lid
Exterior Painted Steel
Interior Steel
Casters 4 Lockable
Warranty 1 Years Parts / 90 Days Labor



This product ships directly from Scilogex, ensuring fast delivery, proper handling, and factory quality. When you purchase Scilogex, you’re backed by a trusted name in laboratory equipment—known for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
